ORIGIN ACOUSTICS

Origin TF37EX 2 Way Ultra Thin Marine InCeiling Speaker

Origin TF37EX 2 Way Ultra Thin Marine InCeiling Speaker

SKU:OA-TF37EX

Regular price $0.00 AUD
Regular price $0.00 AUD Sale price $0.00 AUD
Sale Sold Out

Email: sales@oceanicdistribution.com for any sales enquiries

Origin Acoustics TF37EX ThinFit Speaker

Key Features

  • Enhanced cone excursion for improved bass response
  • Weather-resistant frame material for outdoor adaptability
  • Advanced crossover design for optimal sound clarity
  • Low-profile design for seamless home integration
  • Unique progressive suspension controlled excursion
  • 2 Way Ultra Thin Marine In-Ceiling Speaker
  • 4 x 3.5" Glass Fiber Woofer (7" Equivalent)
  • 3/4" Aluminium Tweeter
  • 89dB Sensitivity
  • 100Hz - 20kHz Frequency Range
  • 5-100 Watt Power Handling
  • Includes Magnetic Grill (Matches Director 6 & 8")
  • Explorer Series Marine Rated

Product Overview

Immerse yourself in the premium sound experience with the Origin Acoustics TF37EX loudspeaker. Featuring advanced cone excursion for enriched bass, this weather-resistant device can be utilized both indoors and outdoors. With inventive crossover design, the loudspeaker ensures sonic clarity. Its low-profile design aptly fits your home décor while the progressive suspension offers controlled sound excursion.



TF37EX
Part:   STF3700EX
Woofer:   Quad 3.5” (89mm) Polypropylene
Tweeter:   ¾” Aluminum
Freq. Response (-10db):   120Hz-20kHz
Power RMS:   30W
Power Peak:   100W
Impedance:   6 ohm
Diameter:   244mm
Cutout Diameter:   222mm
Grille Diameter:   254mm
Mounting Depth:   36mm
Temperature Range:   177˚C  to -20˚C

Resources

Manual

DataSheet
